Machine performance:
1. This machine specializes in silk-screen printing of circular patterns and is used for high-precision printing of patterns and texts such as fishing rods, golf clubs, water pipes, etc.
2. There are upper and lower gears at the back of the mold of the brush, which can automatically rotate and return to the original position after printing, so it is capable of multi-color overprinting.
3. The microcomputer controls the action of each function, with a high degree of automation and simple and convenient operation. Built-in four-digit automatic counter.
4. The total stroke is 400, and the printing stroke and speed are adjustable to meet different printing requirements.
5. The worktable can be fine-tuned up and down, left and right, and plane swing angle, which is convenient and quick to adjust.
6. Pneumatic printing and scraping control with pressure adjustment system, independent printing and ink return speed control.
7. Microcomputer system controller with stable and reliable performance.
8. High-quality sensors and perfect fault alarm system.
9. Convenient foot switch, simple operation and convenient maintenance.
10. Light and strong alloy die-casting parts and wear-resistant imported bearing sleeves.
11. International famous brand pneumatic components.
Machine parameters:
Worktable size: 200mm
Maximum screen frame size: 80*1200mm
Maximum printing area: Φ100*1000mm
Maximum printing speed: 1200pcs/h
Air pressure: 4-6bar
Dimensions: 1250*1100*1450mm
Body weight: 200KG
