Machine performance:
1. This screen printing machine is widely used in the high-precision printing of surface patterns and texts on various packaging containers such as daily chemicals, medicines, food, and electronic devices, toys, tools, etc.
2. It can meet the arc surface printing requirements of cylindrical, elliptical and other special-shaped containers, and it is compatible with containers made of plastic, glass, metal and other materials.
3. This machine realizes the intelligent control of the whole machine through programmable controller (PLC) and advanced touch screen .
4. A brand-new transmission system is composed of advanced imported motors, variable speed devices and pneumatic components to achieve control functions such as stepless speed change, synchronous transmission, automatic alignment, and no bottle no printing.
This screen printing machine comes with features：
Automatic feeding conveyor belt system
Flame surface treatment system
Infinitely variable speed control system
Synchronous delivery system
Automatic prealignment system
No bottle no printing system
UV curing system
Machine parameters:
Circular printing diameter: 20~110mm
Circular printing height: 0~280mm
Flat printing diameter: R20~R180mm
Flat printing height: 20~280mm
The fastest printing speed: 3600pcs/hr
Power requirements (single machine): AC380V 3Phase 50Hz
Rated power (single machine): 7.5KW
Air pressure requirement (single machine): 5～7bar
Machine size (single machine): 2000*1200*1750mm
Machine weight (single machine): 1000kg
