1. Mature models, complete functions, one machine with multiple functions, simple operation, PLC control, human-computer interaction touch screen operation, and digital control.

2. Both the left and right shuttles adopt servo, which can be set arbitrarily within the range of position and stroke, with high accuracy and low noise.

3. The oil supply mechanism of the oil cup is closed, the ink is not easy to volatilize, and the ventilation interface is reserved on the top, which is environmentally friendly, energy-saving and safe.

4. Independent ink-drawing and printing and optional simultaneous ink-drawing and printing sequence are optional, printing pressure is independently controllable, speed and delay can be set, and it has the function of 2 simultaneous printing and 2 separate printing.

5. The equipment is equipped with double counting function, beat display, semi-automatic and full-automatic mode, manual and single-action tuning mode, the design is very user-friendly, easy to learn and practical, the operation is minimal, and the functions are many.

6. Other devices can be connected and docking function.

7. Optional additional functions: 1. Vacuum suction; 2. Rotating fixture; 3. Automatic positioning fixture; 4. Other special functions can be customized.

Steel plate size: 100*150mm

Maximum printing height: 250mm

Plastic head up and down stroke: 75mm

Printing speed: 800pcs/hr

Power supply: 220V 50/60HZ 600W

Maximum oil cup diameter: Φ90mm

Air pressure: 5bar

Machine size: 850*1000*1500mm

Weight: 200kg
