Machine performance:
1. The motor is designed for vertical lifting, adopting precise guide rail to guide the rapid and steady lifting, easy maintenance, long-term operation, and high stability and precision. Innovative structure, strong and light, save energy.
2. The left and right printing adopts motor drive design, precise guide rail guidance, fast running, stable and smooth, and accurate positioning.
3. The turntable is driven by a precision divider (originated in Taiwan) and driven by a motor.
4. Easy and quick to change plate/frame/position, touch screen operation greatly reduces clamping time and increases productivity.
5. The man-machine interface is fully numerically controlled, and it provides multiple function settings to meet the perfect requirements of operation data, standardization, and humanization.
6. Equipped with emergency stop switch, safety reset and automatic error detection warning, complete safety protection.
Remarks: This machine can add automatic loading and unloading manipulators, plane vacuum suction... functions according to customer needs.
Machine parameters:
Left and right stroke: 500mm
Up and down stroke: 75mm
Worktable size: 300*500mm
Printing area: 250*400mm
Maximum size of screen frame: 400*750mm
Printing speed: 800pcs/hr
Air pressure: 5-6BAR
Machine size: 950*1200*1600mm
Weight: 350kg
