1. Using microcomputer program to control each operating function and built-in multiple printing modes, easy to operate and simple to set

2. Built-in automatic four-digit counter, convenient to record the number of printed products

3. The fuselage adopts high-quality aluminum alloy structure, and the surface is painted with high temperature, which is light and solid, beautiful and durable

4. The oil stick is inked, easy to assemble, disassemble and clean

5. Independently adjust the up and down stroke, speed and depth device of the rubber head, greatly improving production efficiency and debugging speed

6. The speed of each action can be adjusted independently, and the adjustment position has a scale mark

7. Automatically balance the oil knife, scraping oil cleanly

8. The worktable and each ink tray can be adjusted independently for X, Y, axis angle, accurate color registration, and improve efficiency

9. It is possible to stick ink twice and transfer printing once to obtain larger printing ink

10. You can go back and forth without dropping the glue head to prevent the ink from drying when you stop

11. The whole machine runs fast, stable and low noise

12. The optional machine head can be adjusted and raised to facilitate the replacement of ink, plastic head, steel plate and parts

13. Pneumatic components adopt precise pneumatic components and battery valve configuration to extend the service life and performance of the components

14. Equipped with a pedal emergency cut-off system, which is convenient for a single trial printing and adjustment of the machine and emergency stop operation, in line with international industrial safety standards.

Standard steel plate size: 100*200mm

Printing area: 100*150mm

Printing speed: 3500pcs/hr

Air pressure: 5-7bar

Power supply: 110/220V 50/60HZ

Body size: 1250*1000*1650mm

Body weight: 260kg
