1. Using microcomputer program to control each operating function and built-in multiple printing modes, easy operation and simple setting

2. Built-in automatic four-digit counter, convenient to record the number of printed products

3. The fuselage adopts high-quality aluminum alloy structure, and the surface is painted with high temperature, which is light and solid, beautiful and durable

4. The oil stick is inked, easy to assemble, disassemble and clean

5. Independently adjust the up and down stroke and speed of the rubber head and the depth device, which greatly improves the production efficiency and debugging speed

6. The speed of each action can be adjusted independently

7. The adjustment position has a scale mark

8. Automatically balance the oil knife, scraping oil cleanly

9. The worktable and each ink tray can be adjusted independently for X, Y, axis angle, accurate color registration, and improve efficiency

10. It is possible to stick ink twice and transfer printing once to obtain larger printing ink

11. You can go back and forth blankly without dropping the glue head to prevent the ink from drying out when you stop for a while

12. The whole machine runs fast, stable and low noise

13. The optional machine head can be adjusted and raised to facilitate the replacement of ink, plastic head, steel plate and parts

14. The four-color or more transport belt pad printer is equipped with a hot air device to ensure that the ink is dry during fast printing

15. Each model has an optional sealed oil cup, with high ink utilization rate, good working environment and reduced odor

16. Pneumatic components adopt precise pneumatic components and battery valve configuration to extend the service life and performance of the components

17. Equipped with standard procedures and non-standard programming, breaking through the general mechanical performance, unlimited programming times of ink extraction and printing

18. Equipped with a pedal emergency cut-off system, which is convenient for trial printing and adjustment of the machine and emergency stop operation, in line with international industrial safety standards.

• Steel plate size: 100*150mm

• Printing area: 60*120mm

• Center distance between two oil basins: 127mm

• Up and down stroke: 75mm

• Height of printing work piece: 100mm

• Front and back stroke: 160mm

• Printing speed: 800pcs/hr

• Air source: 6bar

• Body size: 1300*1100*1600mm

• Weight: 230kg
