Machine performance:
1. The single-chip IC cooperates with the touch panel to compile the action program;
2. The microcomputer controls the actions of each function, and the operation is simple and convenient. It is equipped with a 4-digit automatic counter to count the number of printing;
3. Full cast aluminum body with metal paint on the surface;
4. Double-column lifting structure, stable and high precision;
5. The left and right strokes are adjustable, and the photoelectric eye switch limit controls the stroke, which can be adjusted independently;
6. The angle of the scraper/returning ink knife can be adjusted arbitrarily;
7. The squeegee constant pressure device ensures the stable pressure during the printing process;
8. The front and back, left and right, rotation angles of the worktable are finely adjusted and locked;
9. The position of the screen frame can be adjusted front and rear, left and right, horizontal, height;
10. Aspirating stainless steel table top, adsorb various film products;
11. Equipped with Taiwan CEC hydraulic buffers up and down to eliminate printing vibration;
12. Action mode selection: automatic|semi-automatic|manual;
13. Starting method: panel|foot switch;
14. Scraper pressure control: pressure regulating valve constant pressure.
Machine parameters:
Worktable size: 300*500mm
Maximum printing area: 250*400mm
Substrate thickness: 80mm
Maximum screen frame size: 400*600mm
Printing speed: 800-1000pcs/hr
Power supply: 110V/220V 50W
Gas source requirements: 5-7BAR
Machine size: 800*600*900mm
Weight: 125kg
