Used in plastics, toys, electrical appliances, gifts, daily necessities industry. It is especially suitable for small plane, convex and concave surface and other substrates.

1. The printing speed is fast, and the printing of six colors is completed at one time.
2, accurate positioning, six printing positions using pneumatic lateral pressure positioning, accurate and stable.
3. The performance is stable, and the whole machine is controlled by the world's advanced microcomputer controller.
4. Equipped with four-digit automatic counter.
5. Adjustable delay function and adjustable printing speed to meet different printing requirements.
6. According to the needs of customers, preset two functional programs, single-cycle printing and automatic printing.
7. Six-color independent adjustable oil basin, the color adjustment is simple and convenient.
8. The upper and lower stroke of the rubber head can be adjusted independently, and the speed can be adjusted independently, flexible and convenient.
9. Using the latest pneumatic components of FESTO company in Germany, the power is smooth, strong and durable.
10. The operation panel adopts sensitive light touch system, and the transfer printing function can be selected directly, which is agile and easy to use.

Steel plate size: 100000 * 150mm

Printing area: 75 * 120mm

The center distance between two oil basins: 110mm

Workbench surface area: 160x 200mm

Printing workpiece height: 100mm

Travel before and after the rubber head: 200mm

Print speed: 800pcs / hr

Gas source: 6bar

Body size: 1150 * 1000 * 1600mm

Weight: 190kg
