The machine is widely used in PET, PVC, transfer paper (film), ground heating film, geothermal film, electric heating film, flower paper, film, nameplate, flexible circuit board, mobile phone keys, 3M glue, glue, film switch, trademark radium, scraping card, self-adhesive label, barreled paper, ribbon, aluminum foil, copper foil and other drum materials. PET, PVC, PC, OBB, non-woven, web paper and other packaging materials printing. Suitable for self-adhesive, transfer paper, aluminum platinum paper, Tedolong, self-adhesive trademark paper, label nameplate, film switch and surface glazing, and other packaging materials.

1. PLC program control circuit.

2. Vertical structure, the screen is vertically lifted up and down, and the printing carriage moves left and right.

3. The printing (servo motor) and the screen lifting (air cylinder) adopt independent drive sources, with coordinated movements and stable and adjustable speed.

4. The printing turret is driven by the servo system, and the photoelectric eye controls the stroke, which can be adjusted independently.

5. Taiwan or South Korea cylinder drives the screen to move up and down, smoothly.

6. Overall precision grinding high-strength hardness platform, uniformly distributed suction holes.

7. High-strength vacuum suction pump, strong vacuum adsorption, to ensure accurate multi-color registration.

8. The horizontal and vertical direction of the mesh arm is equipped with precision fine-tuning handles, which makes fine-tuning precise and easy to register and register.

9. There are two printing modes: manual and full-automatic, and the number of automatic printing interval (printing speed) can be set freely.

10. Independently controlled head lifting device, squeegee/returning knife, screen loading and unloading and screen cleaning are convenient.

11. The left and right net clamp arms are installed with the plate spacing adjustment device, which is convenient to adjust.

12. The angle of scraping and ink return can be adjusted, and the pneumatic automatic synchronization off-screen device can be selected according to the printing conditions.

13. The base of the printing frame, the lifting sliding sleeve, the printing beam, etc. are castings.

14. The material is conveyed by a servo motor and a fine grinding rubber roller (suction roller can be customized), and the conveying length can be digitally set on the touch screen.

15. Color mark sensor positioning, precise control of the material belt stroke, to ensure accurate overprinting.

Feeder characteristics:

1. Photoelectric control discharge to avoid scratches on the material surface.

2. The discharge speed and time can be adjusted at will.

3. The starting speed of discharge can be adjusted at will, and the starting frequency rises slowly from 0 to running, so as to avoid starting too fast and causing scratches on the material surface.

4. Equipped with automatic tear protective film device.

Dryer characteristics:

1. Circulating hot air drying, temperature adjustable, automatic winding.

2. The oven covers a small area and varies in length from 32 to 60 meters. It can achieve low temperature drying, ensure that the printed material does not shrink and deform, and is conducive to multi-color printing.

3. The fuselage is equipped with thermal insulation layer for thermal insulation and energy saving.

• Maximum printing area: 400*500mm

• Maximum screen frame area: 550*850mm

• Platen size: 460*650mm

• Maximum feeding width: 420mm

• Material unwinding/unwinding from warp: 600mm

• Material core: 75mm

• Maximum printing speed: 2500pcs/hr

• Air pressure: 4-8kg/cm2

• Machine size: 2300x1100x1600mm;

• Whole machine weight: 1600kg
