Machine performance:
1. All positions are sensored by electric eyes, with accurate position and excellent performance.
2. Accurate positioning. The worktable can be fine-tuned and fixed in front and back, left and right, and angles, which is accurate and stable.
3. Stable performance, the whole machine is controlled by the world's advanced microcomputer controller.
4. The machine head can be raised, the oil roller can be inked, and it is convenient to assemble, disassemble and clean.
5. Built-in four-digit automatic counter.
6. You can stick the ink twice and transfer printing once to obtain a thicker printing oil film.
7. Automatically balanced scraper, scraping oil cleanly.
8. Adjustable delay function for each position and adjustable printing speed to meet different printing requirements.
9. It can go back and forth without falling glue to prevent the ink from drying up when it stops for a while.
10. The lifting and lowering of the scraper can be adjusted independently, and it can be applied to steel plates of different thicknesses.
11. The up and down stroke of the rubber head is independently adjustable, and the speed is independently adjustable, which is flexible and convenient.
12. According to customer needs, preset two functional programs, single-cycle printing and full-automatic printing.
13. Adopting imported pneumatic components, the power is smooth and strong, and it is durable.
14. With special shock absorption device, the machine operates very smoothly and has superior performance.
15. The alloy cast aluminum body structure is light and strong, and the precision structure is highly efficient.
16. The operation panel adopts a sensitive touch system, and the pad printing function can be directly selected. It is quick to respond and easy to use.
17.This monochrome pad printer can print on flat and curved surfaces, can enlarge the oil cup, and can add more plastic heads to improve efficiency.
Machine parameters:
Number of printable colors: 1
Cylinder front and rear stroke: 350mm
Steel plate size: 300×300mm
Workbench area: 115×280mm
Maximum printing diameter: Φ280mm;
Pad printing speed: 1000pcs/hr
Maximum printing pressure: 6bar
Size: 1100 * 800 * 1550mm
Weight: 260kg
