Machine performance:
1. Microcomputer control, can be used fully or semi-automatically.
2. Suitable for precision flat screen printing of small product design.
3. Fully pneumatically driven design, no need for power supply.
4. Beautiful appearance and easy operation.
5. The body is made of cast aluminum, beautiful and considerate.
6. The pressure, balance and angle of the squeegee can be adjusted arbitrarily to suit different printing requirements.
7. The worktable can be adjusted up and down, front and rear, and left and right. The button with scale can be adjusted according to the size of the product position, which can accurately adjust the position.
8. Adopt high-precision linear guide to ensure printing precision while increasing wear resistance and durability.
Machine parameters:
Worktable size: 150*200mm
Printing area: 150*200mm
Substrate thickness: 200mm
Maximum screen frame size: 300*500mm
Left and right stroke: 200mm
Printing speed: 1200pcs/hr
Air pressure: 5-7bar
Power supply: 220V
Dimensions: 700*400*800mm
Weight: 35kg
